Ametek Land Cyclops L Series User Manual

Portable Thermometers
User Guide
Cyclops L
6 - 4
Displaypanel
Temperature
reading
Targetgraticule
(1/3°circle)
Fig.6-3Cyclops eyepieceoptics
Theeyepieceallowsyoutolookintothethermometerandviewthetarget
scene.Accuratetargetdenitionisprovidedbythewideangle(9°)eldofview
andsmall,clearlydened(1/3°)targetgraticule.
Theeyepiececanbefocusedmanuallytomatcheachuser’seyesight
characteristics:
1) Usetheviewndertoviewaplain,brightlylitbackground,suchasablank
wall.
2) Rotatetherubbereyecuptobringthegraticulecircletothesharpest
possiblefocus.Theeyepieceisnowadjustedtoyoureye.
3) Adjustthemainfocusingringtobringthetargetscenetothesharpest
possiblefocusonthegraticulecircle.
Whenatemperaturereadingistaken(thetriggerpressed),themeasuredvalue
isdisplayedintheeyepiecedisplaypanel.Thetemperatureisdisplayedinthe
unitsselectedfromtheMainMenu.
