Ametek Land Cyclops L Series

Portable Thermometers
Cyclops L
ACCESSORIES &
SPARE PARTS
12
12.1 Accessories
Type 110 & Type 135 Close-up Lenses
Type110(PartNº802007)andType135(PartNº802008)Close-uplenses
enabletheCyclopstofocusontargetsatdistancesthataretoocloseto
measurewiththestandardlens.
TheType110lenshasaxedfocusat215mm/8.5in,withaminimumtarget
sizeof0.4mm/0.016in.Atypicalapplicationforthislensishotlament/wire
observation.
TheType135lenshasafocusrangeof450mm/17.7into620mm/24.4in,with
aminimumtargetsizeof1.8mm/0.07in.Atypicalapplicationforthislensis
calibrationonsmallaperturefurnaces.
Fig.12-1Type110andType135Close-uplenses
Protective Hard Carrycase
TheHardCarrycase(PartNº801777)isarugged,lightweight,waterproofand
shockproofinjection-mouldedbox,givingfullenvironmentalprotection.Itis
suppliedwithcustom-cutfoamcushioning,withcut-outsforthethermometer
andanysuppliedaccessories,allowingallitemsofthe‘kit’tobekepttogether
forconvenience.
Dimensions:360x290x165mm/14.2x11.4x6.5in(widthxlengthxdepth)
Fig.12-2HardCarrycase(open&closedviews)
User Guide12 - 0
