Ametek Land Cyclops L Series - Latched, Route Modes, and Bluetooth Heartbeat

Appendix 1 - 3
Cyclops LPortable Thermometers
User Guide
1degresolutionexample
    ‘B’ ‘3’ ‘C’ ‘E’ ‘+1.000’ ’CR’’LF’
   { ‘B’ ‘3’ ‘C’ ‘T’ ‘+1.000’ ’CR’’LF’
orifdisabled { ‘B’ ‘3’ ‘C’ ‘T’ ‘+OFF’ ’CR’’LF’
0.1degresolutionexample
    ‘B’ ‘3’ ‘C’ ‘E’ ‘+1.000’’CR’’LF’
   { ‘B’ ‘3’ ‘C’ ‘T’ ‘+1.000’’CR’’LF’
orifdisabled { ‘B’ ‘3’ ‘C’ ‘T’ ‘+OFF’ ’CR’’LF’
Thereceivingdeviceshouldsenda‘*‘handshaketoindicatetermination
packetreception.
Advanced – Latched Interval Mode packet
Whenthetriggerislatched,thedatastreamisexactlyasin‘burstmode’above
exceptthat
 a) thedatarateisusersettable
 b) Characterinterpretationasaboveexcept
  (i) Packet   ‘4’-advanced–latchedmodepacket
 c) The2lineterminationpacketissentwhenthetriggerisunlatched
Advanced – Route Mode packet
Whenthetriggerispressed,thedatastreamisexactlyasin‘classicmode’
aboveexceptthat
 a) Characterinterpretationasaboveexcept
  (i) Packet   ‘5’-advanced–routemodepacket
 b) the‘HOLD’terminationpacketisNOTsent
Bluetooth Heartbeat
TokeeptheBluetoothlinkalive,andtoestablishtheloggerprogramisrunning,
thefollowingdummydatacanbesent
1degresolutionexample
    ‘B’ ‘0’ ‘C’ ‘x’ ‘xxxxxxx’’CR’’LF’
0.1degresolutionexample
    ‘B’ ‘0’ ‘C’ ‘x’ ‘xxxxxxxx’ ’CR’’LF’
Thereceivingdeviceshouldsenda‘*‘handshaketoindicateheartbeat
reception.
