Ametek Land Cyclops L Series User Manual

Portable Thermometers
User Guide
Cyclops L
12 - 4
5) Replacethe3grubscrewsandtighten
themgentlyandevenly(Fig.12-11).
Note:3sparegrubscrewsareincludedin
theLERadaptorkit.
Fig.12-10
Fig.12-11
Fig.12-12
6) ScrewtheLERadaptorinorouttosuit
yourrequirements(Fig.12-12).
 TheCyclopsthermometercannowbeused
withtheLERAdaptortted.
12.3.2 Using a Cyclops with the LER adaptor
Thethermometershouldbeusedexactlyas
before,althoughitwillbeobservedthatthereis
areducedmagnicationofthescenedisplayed
throughtheeyepiece.
Itispossibletomovetheeyepieceawayfromtheeyebyatleast50mm
andstillseethefulleldofview,themeasurementcircle,andtheinternal
temperaturedisplay.
TherubbercupontheLERadaptorcanbeusedtoadjusttheeyepiecetoobtain
thebestpossiblefocusonthegraticulecircle,althoughthisisusuallyless
criticalthanforthestandard,highmagnication,eyepiece.
