Ametek Land Cyclops L Series User Manual

Portable Thermometers
User Guide
Cyclops L
7 - 10
7.5 Menu Mode
WhenthethermometerisinMenu Mode,themenuoptionsavailableinthe
Cyclops thermometercanbeaccessed.Thisallowsyoutoviewandcongure
thesetupofthethermometerandselecttheoptionsthatbestsuityour
temperaturemeasurementrequirements.
1) ToaccessMenu Modepressthe
key.
 TounlockMenu Mode when Operator Emissivity Modeisselected,refer
toSection7.4
 Themainmenuoptionsaredisplayedasicons.Thereare14mainmenu
options,althoughonly8iconsaredisplayedwithinthescreenatanyone
time(SeeFig.7-8).
2) Usethe
and keystoscrollthroughthemenuoptions.Thecurrently
selectablemenuitemishighlightedbya‘ashing’frame.
3) Toselectamenuoption,pressthe
key.
 Whenamainmenuoptionisselected,theavailablesub-optionsare
displayed.
4) Usethe
and keystohighlighttherequiredsub-optioninthemenu.
Pressthe keytoselectit.
5) Forsub-optionswhereanumericvalueisrequired,usethescrollkeys
toselecttherequirednumericvalue,thenclickonthe
keytosetthis
value.Forexample,tochangetheemissivityfrom1.00to0.78,selectthe
Emissivitymenu,thenpressandholdinthe
keytochangethevalue
from1.00to0.78.Ifyou‘overshoot’thevalue,usethe keytoreturn
totherequiredvalue
 Whenchangingnumericvalues,akeyacceleratorisused.Thelongeran
arrowkeyishelddown,thebiggerthesizeofstepchangebecomes.On
thedisplaypanel,thedigitbeingincrementedishighlightedtoindicatethe
sizeofstepbeingmade.
6) Whenyouhavesetarequiredparametervalue,pressthe
keytoreturn
tothemainmenuoptions.
Fig.7-8CyclopsmainmenuiconsMenu Mode
