Cyclops LPortable Thermometers
User Guide
7.3 Route Mode
Routemodeisaccessedviathemenusystem(SeeSection7.4.4).
Routemodeallowsyoutoloaduptonine*pre-denedroutes(i.e.setsof
locationIDs,emissivities,timefunctionsetc.)intotheCyclops.Eachroutecan
containupto99locations.
Thismodeisidealforuserswhoneedtotakeanumberofreadingsona
regulartouroftheirplantorprocess.Thepre-loadedlocationshelptoguide
theuseralongeachroute.
Ifselected,whenchoosingtheroutenumber,thelocationwillincrement
automaticallyoneachtriggerpress.
Tonavigatearoutemanually,usethe
and keystohighlighttherequired
locationandpressthethermometertriggertotakeameasurement.
Note:Otherthanclearingroutetemperaturemeasurements,thereisno route
datamanagementfacilityintheCyclopsinstrumentitself:Routesmustbeset
upandloadedintotheCyclopsusingtheexternalsoftware,whichisavailable
fordownloadtoPCandmobiledevicesat:
www.landinst.com/software-downloads
Onceallmeasurementsonaroutehavebeentakenandstored,theycanbe
downloadedfromtheCyclopstotheexternalsoftware.
Themeasurementcanbeclearedfromaroutebyusingthemenuto
navigatetotheRoute Clearicon.
RefertotheCyclopsLoggerSoftwareUserGuideforinstructionson
howtoprogramaroute.
* Cyclops v2.00 = 9 routes, v1.00 = 4 routes
Previous
location
Current timeRouteNumber
The>>Symbolindicates
‘Autoincrement’
Current
location
Next
location
RouteLocationID
(upto8characters)
Timefunction
processingat
location
Emissivityat
location
Time/
dateof
captured
reading
Fig.7-5TypicalRoute Modedisplay
