7 - 1
Cyclops LPortable Thermometers
User Guide
DISPLAY PANEL MODES
7
7.1 Introduction
TheLCDdisplaypanelhasfourbasicmodesofoperation:
• MeasureMode
• MenuMode
• RouteMode
• OperatorEmissivityMode
Whenthethermometerisswitchedon,anintroductionscreenisdisplayed.
Aftertheintroduction,ascreenisdisplayedindicatingthecalibrationstatus
–indicatingwhethertheCyclopsisdueforanannualcalibrationcheck.This
requiresthecorrectdatetobesetontheRealtimeClock(RTC),seeSection
7.6.13.Thiscalibrationstatuscheckcanalsobedisabledinthesamesub
menu.TomoveontonormalCyclopsoperation,hitanykey.
Thisscreentimes-outautomaticallyandisreplacedbytheMeasure Mode or
Route Modedisplay.
ToaccesstheMenu Mode,pressthe
(Enter/select)keyonthekeypad.
Note
Intheeventofafaultcausinglossofon-boardmemory,anerrormessage
willbedisplayednearthebottomofthescreen.Foralistoferrorcodesand
theirmeanings,seeAppendix2
7.2 Measure Mode (Classic, Burst and Latched Trigger Operation)
WhentheunitisinMeasureMode,thedisplayindicatesthePeak,Continuous,
Average,andValleytemperaturevaluessimultaneously.Ifyouhavea
Cyclops 055L,thedisplayshowsthespecialMeltmastermodetemperature
insteadoftheAveragetemperature.
OnthesideLCDdisplaypanel,theselectedmeasurementtypeisdisplayed
largerandbolderthanthethreenon-selectedmeasurementtypes.Notethat
thethermometermeasuresinallfourmeasurementtypescontinuously.
