Portable Thermometers

User Guide

Cyclops L

9 - 4

10) Aimthethermometerthroughtheviewingwindow/portatthetarget

andfocusthegraticuleontotheareaunderobservation.Checkthatthe

graticuleisfullylledbythetarget,re-positionifnecessary

11) Pressthetriggertostartmeasurement.Themaindisplayandeyepiece

displayareupdatedwiththereading.

12) Releasethetriggertostopmeasurementandfreezethelastrecorded

valueonthemaindisplay.

9.3 Operation (Example 3: route mode)

1) SwitchthethermometeronviatheOn/Oswitch.Theinitialisationscreen

willappearand,afterafewseconds,thescreenwillchangetoshowthe

measurementmodedisplay.

2) Checkthebatterystatus,ensurethatthereissucientbatterylife

remaining.

3) Ifrouteshavenotalreadybeendownloadedtothethermometer,connect

to the Logger SoftwareandfollowthestepsunderRoute Management

initsuserguidetodothis.

4) Setthethermometerintoroutemodeandselectaroutebygoinginto

Menu Mode,openingtheTrigger MenuandselectingRoute Mode,then

selectaroutesavedinmemorybyselectingitsroutenumber(1,2,3or4)

andselectwhetheryouwanttheroutelocationtoauto-incrementalong

theroute.

5) WheninMeasurement Mode,thesidedisplaywillnowshowalist

oflocationsalongtheselectedroute,thesecanbenavigatedbyusing

theupanddownkeys.Threelocationsandtheirmeasurementswillbe

displayed,themiddleoneisthecurrentlyselectedlocationandiswhere

anymeasurementswillbestored.

6) Pressthetriggertostartmeasurement.Thecurrentlyselectedlocationon

thesidedisplayandtheeyepiecedisplayareupdated.

7) Releasethetriggertostopmeasurementandfreezethelastrecorded

valueonthemaindisplay.

8) Thismeasurementwillbestoredwhenanyoftheup,downorenterkeys

arepressed.

9) ThedatastoredonarouteissavedontheCyclopsfordownloadatalater

time;thisisdonefromtheloggersoftwareusingtheDownload Routes

function.

Ametek Land Cyclops L Series User Manual
