Ametek mocon Dansensor CheckMate3 User Manual

Dansensor® CheckMate 3 EN User Guide 41
P/N 300042-I
05/2019
Column
Start
pos.*
Length ** Type Description Note
1 1 8 Numeric O2 [%] Fixed decimal point, eg. "020.9465"
2 10 8 Numeric CO2 [%] Fixed decimal point, eg. "020.9465"
3 19 8 Numeric Balance [%] Fixed decimal point, eg. "020.9465"
4 28 8 Numeric (Not used) Fixed decimal point, eg. "020.9465"
5 37 1 Numeric O2 alarm [0=No alarm 1=High Alarm 2=Low Alarm]
6 39 1 Numeric CO2 alarm [0=No alarm 1=High Alarm 2=Low Alarm]
7 41 1 Numeric (Not used)
8 43 6 Numeric Product number [Integer] No decimal point (e.g. "000032")
9 50 8 Text Date [MM/DD/YY] / [DD/MM/YY] Variable according to set-up
10 59 8 Text Time [HH:MM:SS]
11 68 40 Text Product name [Text] Left alligned
12 109 40 Text Product barcode [Text]
13 150 24 Text CheckMate II S/N [Text]
14 175 40 Text User ID [Text]
15 216 37 Text User field 1 [Text]
16 254 37 Text User field 2 [Text]
17 292 37 Text User field 3 [Text]
18 330 37 Text User field 4 [Text]
19 368 37 Text User field 5 [Text]
20 406 100 Text Note [Text]
21 507 14 Text SW version [Text]
22 522 1 Numeric Measure mode
[0=Continuous, 1=manual spot, 2=auto spot 3=intermitted]
23 524 6 Numeric Sample time [seconds] Fixed decimal point plus sign, eg. "+005.0"
24 531 6 Numeric Measure delay at intermitted [minutes] No decimal point
25 538 1 Numeric Alarm 1 type [0=Off, 1=high, 2=Low]
26 540 1 Numeric Alarm 1 gas [0=O2, 1=CO2
27 542 8 Numeric Alarm 1 concentration [%] Fixed decimal point, eg. "020.9465"
28 551 1 Numeric Alarm 2 type[0=Off, 1=high, 2=Low]
29 553 1 Numeric Alarm 2 gas [0=O2, 1=CO2
30 555 8 Numeric Alarm 2 concentration [%] Fixed decimal point, eg. "020.9465"
31 564 1 Numeric Alarm 3 type[0=Off, 1=high, 2=Low]
32 566 1 Numeric Alarm 3 gas [0=O2, 1=CO2
33 568 8 Numeric Alarm 3 concentration [%] Fixed decimal point, eg. "020.9465"
34 577 1 Numeric Alarm 4 type[0=Off, 1=high, 2=Low]
35 579 1 Numeric Alarm 4 gas [0=O2, 1=CO2
36 581 8 Numeric Alarm 4 concentration [%] Fixed decimal point, eg. "020.9465"
37 590 1 Numeric Alarm 5 type [0=Off, 1=high, 2=Low]
38 592 1 Numeric Alarm 5 gas [0=O2, 1=CO2
39 594 8 Numeric Alarm 5 concentration [%] Fixed decimal point, eg. "020.9465"
40 603 1 Numeric Alarm 6 type[0=Off, 1=high, 2=Low]
41 605 1 Numeric Alarm 6 gas [0=O2, 1=CO2
42 607 8 Numeric Alarm 6 concentration [%] Fixed decimal point, eg. "020.9465"
43 616 1 Numeric Note [0=Off, 1=At alarm, 2=At no alarm, 3= Always, 4=Always]
44 618 1 Numeric User field 1 required [0=no, 1=Always, 2=Once]
45 620 1 Numeric User field 2 required [0=no, 1=Always, 2=Once]
46 622 1 Numeric User field 3 required [0=no, 1=Always, 2=Once]
47 624 1 Numeric User field 4 required [0=no, 1=Always, 2=Once]
48 626 1 Numeric User field 5 required [0=no, 1=Always, 2=Once]
49 628 6 Numeric Device temperature [°C] Signed value and fixed point
(eg. "+023.0" or "-003.2")
50 635 6 Numeric Atmospheric pressure [mbar] No decimal point
51 642 1 Numeric Invalid measurement [0=No, 1=Yes]
Total: 644
Chars in ASCII (x4 in UNICODE) +CRL
F
* Only when all elements are selected and format is ASCII.
** Length: Fixed length. When unicode length must be multiplied by 4.
Fixed decimal placement. Leading zero in numbers. Gas concentrations are always in % buth with ppm resolusion (regardless of accuracy) e.g. "020.9465"
Example:
000,8395;000,3200;098,8405;000,0000;0;0;0;000002;27/02/08;16:43:39;Product 2;
Serial data dump specification

Ametek mocon Dansensor CheckMate3 Specifications
