52 User Guide EN Dansensor® CheckMate 3
P/N 300042-I
05/2019
Gas connection
Gas inlet Sample hose: Length 60 cm, Ø0,5mm
Sample type/connector: Needle 0,8x40mm
or
SmartPen 0,8x9mm
Filter/Water trap: 0,2 μ
Gas outlet Connection for hose (inner diameter Ø 3mm)
Basic specifications
Warm-up time Operational after 10 min.
1
(60 minutes to full specifications)
Measuring ranges 0-100 % O
2
and 0-100% CO
2
Ambient temperature Operational: +0 to +45 °C, less than 95 %RH,
non condensing
Storage: -20°C to +60°C, less than 95 %RH,
non condensing
Ambient pressure Operational:900 hPa to 1050 hPa
Measurement gas Inert gasses (O
2
, CO
2
, N
2
or Ar), less than 95 %RH,
non condensing.
Measurement gas flow 27 to 40 ml/min. (Typical flow 34 ml/min.)
Measurement gas temperature 5 °C to 35 °C
Sample pressure range Ambient +100 mbar -100mbar
2
1
Warm-up time is shortened at temporary power interrupts.
2
The flow will be lower than 27 ml/min when sample pressure is lower than atmospheric pressure.
