PARSTAT MC Hardware Manual
PARSTAT MC Hardware Manual 59
5.5. Cell Cable Pinouts
Table 3. PMC Cell Cable Pin Outs
Pin
Signal
A1
SENSE
See section 3.4.2.
A2
WORKING
See section 3.4.2.
A3
COUNTER
See section 3.4.2.
A4
REFERENCE
See section 3.4.2.
1
GROUND
See section 3.4.2.
9
GROUND
See section 3.4.2.
2-8
RESERVED
Reserved for future options
10-17
RESERVED
Reserved for future options
