Analog Programming (APG) and Isolated Analog Programming (ISOL)
4-12 M370430-01 Rev B
Voltage-Controlled Current APG Setup
Activating APG Current Mode
To activate APG current mode using an external voltage source:
1. Turn the 9-position mode control to the CAP position or press
the rotary Adjust/Enter control if the mode control is already
at the CAP position.
is displayed on the output voltage display.
2. Turn the rotary Adjust/Enter control to select source
(Voltage source from non-isolated connector).
3. Press the rotary Adjust/Enter control to commit the selected
mode. is displayed on the output voltage display.
4. Select the input source level using the rotary Adjust/Enter
control.
5. Once the desired level has been selected, press the rotary
Adjust/ Enter control to commit the change.
The display will return to the normal display.
Deactivating APG Current Mode
To deactivate the APG current mode:
1. Turn the 9-position mode control to the CAP position or press
the rotary Adjust/Enter control if the mode control is already
at the CAP position.
2. is displayed on the output voltage display.
3. Turn the rotary Adjust/Enter control to select .
4. Press the rotary Adjust/Enter control to commit the change.
The display will return to the normal display.
