Page #174 background imageLoading...
Page #174 background image
Remote Operation
5-40 M370430-01 Rev B
Table 5-11 OPERation Status Register
Bit
Bit Weight
Bit Name
Description
0
1
CALibrating
Indicates that the supply is in CALibration Mode.
1
2
SETTling
Not implemented
2
4
RANGing
Not implemented
3
8
SWEeping
Not implemented
4
16
MEASuring
Not implemented
5
32
Waiting for Arm
Not implemented
6
64
Waiting for Trigger
Not implemented
7
128
CORRecting
Not implemented
8
256
Not Used
Not Used
9
512
SHUTdown Summary
Reflects the summary of the SHUTdown
Sub-Register.
10
1024
Local Lockout
Front panel lockout
11
2048
Current Share Summary
Reflects the summary of the CSHare Sub-Register.
12
4096
Constant Voltage Mode
Reflects the output mode of the supply.
13
8192
Constant Current Mode
Reflects the output mode of the supply.
14
16384
Program Running
Indicates if an Autosequence program is currently
running.
The operation shutdown status register describes the cause of the
power supply shutting down the output. More than one bit may be
active and multiple actions will be required to restart the unit. The
protection shutdown sub-register indicates which protection
mechanisms have caused the power supply to shutdown.
