A-14 | Thermox Series 2000 WDG-IV /I VC / IVCM
12/18 I1_span Analog output 1, 20 ma value R/W
13/19 I1_zero Analog output 1, 0 or 4 ma value R/W
14/20 I2_span Analog output 2, 20 ma value R/W
15/21 I2_zero Analog output 2 , 0 or 4 ma value R/W
16/22 I3_span Analog output 3 , 20 ma value R/W
17/23 I3_zero Analog output 3 , 0 or 4 ma value R/W
18/24 I4_span Analog output 4 , 20 ma value R/W
19/25 I4_zero Analog output 4 , 0 or 4 ma value R/W
1A/26 I_filt1 Filter value for analog output 1 R/W
1B/27 I_filt2 Filter value for analog output 2 R/W
1C/28 I_filt3 Filter value for analog output 3 R/W
1D/29 I_filt4 Filter value for analog output 4 R/W
1E/30 Alm3_value alarm setpoint for process alarm
IQ
Oxygen alarm setpoint for Alarm #3
S2
Value
is always in percent
R/W
1F/31 Alm4_value alarm setpoint for Alarm #2
IQ
Oxygen alarm setpoint for Alarm #4
S2
Value
is always in percent
R/W
20/32 Alm5_value Combustibles PPM alarm #5 setpoint
S2
Alarm #3 setpoint
IQ
R/W
21/33 Alm6_value Combustibles PPM alarm #6 setpoint
S2
R/W
22/34 Alm5_percent Combustibles percent alarm #5 setpoint
S2
R/W
23/35 Alm6_percent Combustibles percent alarm #6 setpoint
S2
R/W
24/36 Alm7_percent Methane percent alarm #7 setpoint
S2
R/W
25/37 Alm8_percent Methane percent alarm #8 setpoint
S2
R/W
26/38 Gas1_time Amount of time oxygen span gas will flow in
seconds
IQ
Amount of time oxygen span gas will flow in
MMSS
S2
R/W
27/39 Gas2_time Amount of time oxygen zero gas will flow in
seconds
IQ
Amount of time oxygen zero gas will flow in
MMSS
S2
R/W
28/40 Gas3_time Amount of time the combustibles span gas
will flow in seconds
IQ
Amount of time combustibles span gas will
flow in MMSS
S2
R/W
