Ammann ARX 40 - Roller Cleaning Procedures

112 ARX 4
1208531 | 03.07.2012
Tab. 9-5 Torque: low-profile cylinder head screws and oval head screws
Tab. 9-6 Torque: Shoulder screws
Tab. 9-7 Torque: Countersunk head screws
Tab. 9-8 Torque: Screw plugs
Tab. 9-9 Torque: Drain cock / hydraulic tank
9.18 Cleaning the roller
After completion of work, clean the roller:
● of major soiling;
● and the lower scrapers of deposits.
Regularly clean completely; at least once a week. When working on cohesive soils,
or with cement and lime stabilizers, complete cleaning must be performed daily.
SW Allen
Srew
diameter
Steel quality
Tightening torque in
Nm
3 M5 10.9 4
5 M8 10.9 10
5 M10 10.9 18
SW Allen
Srew
diameter
Steel quality
Tightening torque in
Nm
6M10 12.9 40
SW Allen
Srew
diameter
Steel quality
Tightening torque in
Nm
6M10 12.9 40
SW hex SW Allen
Srew
diameter
Tightening torque in
Nm
- 5 1/8"thread 13
- 10 1/2"thread 80
27 - M22x1.5 90
Drain cock
Diesel tank Secure the screw connections with ERGO 4207 and tighten by
hand, not with torque.
Hydraulic tank Secure the screw connections with ERGO 4207 and tighten by
hand, not with torque.
