NOTE The edge cutter only operates correctly with one of these two settings. If the
switch is set to “high amplitude / low frequency” (towards the right), the edge
cutter will not be raised automatically.
8.1.2 Operation of the edge cutter
Raise/Lower 1 Operation of the rocker switch (1):
2a Lower: As long as you press this switch right, the edge cutter is lowered.
2b Raise:As long as you press this switch left, the edge cutter is raised.
Sprinkling 1 Press the "Sprinkler" (2) button. The roller drum sprinkler is switched on for
as long as the "Sprinkler" button is pressed.
Water supply 1 Pressing the "Water" (3) button switches on the water supply for the edge cut-
ter.
NOTE The water supply only works if continuous roller drum sprinkling is switched
on.
Vibration 1 Press the "Vibration" (4) button.
The vibration switches on.
NOTE When the vibration is switched on, the edge cutter is raised automatically. The
edge cutter is nonfunctional.
8.1.3 Disks
A cutting disk and a pressure disk are included in the edge cutter's scope of deli-
very.
Cutting disk Using the cutting disk (1) the pavement can be cut at the required position or pave-
ment edges can be straightened.
Pressure disk The pavement edges are compacted at an angle using the pressure disk (2).
