Options 77
1208531 | 03.07.2012
Fig. 8-8 Switching off the power
Removing
the key
1 Turn the red key of the battery cut-off switch right to final position.
2 Now you can remove the key
3 Close the keyhole using the cap provided.
Fig. 8-9 Removing the key
8.8 Traction aid (flow divider)
The flow divider ensures equal drive of the front and rear wheels and thus avoids free
rotation of one wheel.
This function is useful for negotiating inclines with poor adhesion qualities (e.g. loa-
ding the roller via a loading ramp).
Switching on 1 Rotate switch (1) on the operating lever console towards the right.
The “traction aid” is activated and an acoustic signal is sounded.
