Operation 65
1208531 | 03.07.2012
The locking brake closes automatically when the diesel engine is switched off.
NOTE Brake wear due to unnecessary emergency stops!
• In order to save the brakes from unnecessary wear, only perform an emer-
gency stop in emergency situations when driving.
• Only use the locking brake in special cases, e.g. when you stop on a slope.
If the roller starts to roll, move the operating lever slightly in the opposite
direction, so that the vehicle is kept still hydrostatically.
7.12 Sprinkling
7.12.1 Checking water level
Water level indicator
1 You can read the water level on the water level indicator at the rear left:
2a full: You can switch sprinkling on.
2b empty: First refill with water.
7.12.2 Refilling with water
1 Open the screw lid of the water tank at the rear right.
1.1 Use the roller's ignition key to unlock the tank screw lid.
2 Pour water in .
Fig. 7-6 Water tank cover rear right
