Ammann ARX 40 - Key for ARX 4 Wiring Diagram

142 ARX 4
1208531 | 03.07.2012
14.1.1 Key for ARX 4 wiring diagram
Element Description
A1 Diesel tank fuel level display
A2 Voltage display
B1 Horn
B11 Reversing alarm
B12 Warning buzzer, flow divider
B13 Warning buzzer, seat contact delay
E1 Front right low beam light
E2 Front left low beam light
E11 Front right parking light
E12 Front right position light
E13 Front left parking light
E14 Front left position light
E15 Rear right parking light
E16 Rear left parking light
E17 Front right indicator
E18 Front left indicator
E19 Rear right indicator
E20 Rear left indicator
E21 Revolving warning light
E22 License plate illumination
E23 Work light rear
F1 Fuse, hazard flasher
F2 Fuse, parking light 1
F3 Fuse, parking light 2
F4 Low beam light fuse
F5 Fuse, revolving warning light, work light
F6 Fuse, horn
F7 Fuse, display unit, reverse alarm, blinker
F8 Fuse, Seat heating
F9 Fuse, controller, supply
F10 Fuse, controller, outputs
F11 Fuse, sprinkler
F12 Fuse, flow divider, edge cutter
F13 Fuse - vibration
