Operating and display elements 47
1208531 | 03.07.2012
5.2 Error code
The current operating state and the errors recognized by the controller are displayed
above the hour counter.
5.2.1 Display upon start-up
If the machine is not in operation, e.g. the seat contact is not closed, the issue pre-
venting start-up will be displayed:
Tab. 5-1 Error code upon start-up
NOTE The display remains blank when the machine is in operation, in other words,
when it is being driven and/or is vibrating.
If errors are recognized, the error warning lamp lights in addition to the display of the
error code. If more than one error is present, they will be displayed one after the other
at an interval of about 5sec.
5.2.2 Displays during operation
Tab. 5-2 Error code during operation
Display Error Remedy
-11 Seat contact open Sit down
-12 Operating lever is deflected Put the operating lever in the neutral posi-
tion
-13 2 operating levers (optional),
both operating levers deflected
Put the operating lever in the neutral posi-
tion
-14 Parking brake is activated Release parking brake
-15 Diesel engine is not running Start the engine
Display Error Effect Remedy
F21 Operating lever
right
Vehicle standstill. Limited driving is possi-
ble with operating lever left, if present.
Check sensor, wiring harness
and connector of the RC.
F22 Move operating
lever, neutral
switch to right
Vehicle standstill. Limited driving is possi-
ble with operating lever left, if present.
Check sensor, wiring harness
and connector of the RC.
F23 Operating lever
left
Vehicle standstill. Limited driving is possi-
ble with operating lever right.
Check sensor, wiring harness
and connector of the RC.
F24 Move operating
lever, neutral
switch to left
Vehicle standstill. Limited driving is possi-
ble with operating lever right.
Check sensor, wiring harness
and connector of the RC.
F25 Sprinkler potentio-
meter
Sprinkler function switched off. Check sensor, wiring harness
and connector of the RC.
F26 Oil temperature
sensor
Temperature control switched off. Check sensor, wiring harness
and connector of the RC.
