Disposal 137
1208531 | 03.07.2012
Fig. 13-1 Removal and depressurization of the gas struts
NOTE If disposal according to these regulations is not possible, ask your authorized
dealer.
1. saw cut / hole position: Cut or drill into the pressurized tube about 20mm from
the bottom.
2. saw cut / hole position: Cut or drill into the pressurized tube in the bead.
2. Saw cut / drilled hole
1. Saw cut / drilled hole
Piston rod
Bottom
about
Pressurized
tube
X
