Operating and display elements 45
1208531 | 03.07.2012
Hydraulic oil tem-
perature
The Hydraulic oil temperature control lamp lights as soon as the oil temperature
exceeds 85°C. As soon as the temperature exceeds 95°C, error F32 appears as well.
In this condition, the machine can only be driven at 1km/h and the vibration can no
longer be switched on. The machine may only be driven normally again after the tem-
perature has gone below 95°C.
1 Check the function of the hydraulic oil radiator fan.
2 Clean heavy soiling from the radiator body.
Emergency stop If the emergency-stop control lamp lights up while the ignition is on, observe the
following:
1 Release the Emergency Stop button by turning it clockwise (red mushroom
button on the instrument panel).
2 Put the operating lever into neutral position.
3 Sit on the driver’s seat.
4* If the control lamp still continues to be lit: Call a specialist to remedy the prob-
lem.
Diesel reserve After the Diesel reserve control lamp lights up for the first time, the fuel in the tank
will last at least ½h.
1 Top up diesel fuel.
The tank holds 43 liters of diesel fuel.
Pre-heating The pre-heating time amounts to about 15sec. When the motor is started, the Pre-
heating control lamp goes off.
Brake pressure As long as the control lamp for brake pressure is lit, the brake release and supply
pressure of the hydraulic system is not sufficient. As long as this control lamp is
lit, the machine cannot be driven.
1 Check whether the seat contact switch is closed.
2 Check whether errors are displayed.
3* The seat contact switch is closed and the control lamp is still lit: Call a specia-
list to remedy the problem.
Parking light The Parking light control lamp remains lit as long as the parking lights are switched
on.
