6.9 Outputs – Volt Free Relay Programmable
Denion: A relay with voltage free change over contacts for user connecons.
Programming which zones will operate any of the outputs is done via the front Panel.
6.9.1 Ancillary Output TB5 5/6/7
The relay is energised in the alarm condion of a zone that is not isolated.
The contacts are to rated at 1A 30VDC.
This output is not monitored.
6.10 Outputs – Volt Free Relay Non-Programmable
Denion: A relay with voltage free change over contacts for user connecons.
6.10.1 Fault Output TB5 8/9/10
The relay is de - energised in any fault condion.
All faults except “System Faults” are non-latching.
The contacts are rated at 1A 30VDC. This output is not monitored.
6.10.2 Auxiliary Power Output TB12 1/2
An output supplying power, with both the + TB12/1 and – TB12/2 legs fused is provided for ancillary
devices.
➢ The output is rated at 500mA @ 24VDC.
➢ The output is protected against short circuit condions.
➢ In the event of the protecon device operang a fault shall be signalled.
➢ The monitoring is only up to the terminal block and does not extend to the eld.
➢ Current drawn from this output reduces that available to the sounders.
➢ A fault on this output is indicated by the common FAULT LED illuminang steady and
indicaon on the LCD.
6.10.3 Buzzer
The buzzer is required to operate on any alarm, fault or isolate condion. If the buzzer has been
muted there is provision for the buzzer to resound again aer an 8 hour period has elapsed if a new
condion has not occurred. This provision is provided for;
➢ Sounder silenced
➢ Zone isolated
➢ Warning system isolated
➢ External bell isolated
➢ When ed Ancillary control funcons have been isolated.
