7 Adding Control and Monitoring Facilities
The addion of or a combinaon of the modules, boards / cards listed below mounted on the back
pan or the front panel of the FACP provide addional features to a standard panel. All board inputs
or outputs are programmable to any combinaon of zones.
Note: Only one of each board type can be installed in any one panel. The board types are;
1. Relay Board, BRD25EWRB –A or with a change of on board components it can also be
installed remotely on the external communicaons bus as a Remote Relay Board
BRD25EWRB -B
2. Input Board BRD25SIPB -.
3. Sounder Board BRD25SOPB.
4. Brigade Interface Board BRD25BBA.
5. Fire Fan Module consists of a Terminaon Board (BRD25FTB and front panel card
BRD25FCB)
6. Agent Release Module consists of a Terminaon Board (BRD25ATB), front panel card
(BRD25ARB–A) and if required a remote local control staon (BRD25ARB–B).
7. General Indicator Card. BRD25GIB -A
8. Switch and Indicator Card BRD25GIBA
9. LED Annunciator Master ( LAM ) BRD25GIB - E
Note: To add or remove Cards from the FACP programming go to the SYSTEM Menu.
7.1 Internal Communications Connector (RS485)
PCB mounted connectors provide serial communicaons to internal ancillary boards. CN9 on the
Main Card cables to CN1 or 2 on the front panel boards and CN5 on the Main Card cables to CN1 or
CN2 on the back pan boards
