19 Commissioning Of Installed Cards And Boards
Conrm a Card / Board is in use and funconal at the me of commissioning by cking the
appropriate circle.
Cards / Modules ( Front Panel Mounted )
Type
Fied Y/N
Checked Y/N
Funcon / Locaon
Main Card
BRD25MCB-A ( 4 Zone )
Y N
Y  N
Main Card
BRD25MCB-B ( 8 Zone )
Y N
Y  N
Agent Release Module BDR25ARB-A
Order Code: 4310-0012
Y N
Y  N
Fire Fan Module BRD25FCB
Order Code: 4310-0022
Y N
Y  N
Switch and Indicator Card BRD25GIB-B
Order Code: 4310-0030
Y N
Y  N
General Indicator Card BRD25GIB-A
Order Code: 4310-0032
Y N
Y  N
Remote
Agent Local Control Staon BRD25ARB-D
Order Code: 4310-0016
Y N
Y  N
LED Annunciator Master BRD25GIB-E
Order Code: 4310-0037
Y N
Y  N
Boards ( Backpan Mounted )
Input Board BRD25SIPB
Order Code: 4310-0040
Y N
Y  N
Relay Board BRD25EWRB
Order Code: 4310-0530
Y N
Y  N
Fan Terminaon Board BRD25FTB
Order Code: 4310-0022
Y N
Y  N
Brigade Interface BRD25BBA-A
Order Code: 4310-0070
Y N
Y  N
Sounder BRD25SOPB-A
Order Code: 4310-0060
Y N
Y  N
Agent Terminaon BRD25ATB
Order Code: 4310-0012
Y N
Y  N
Other ( List )
Y N
Y  N
Y N
Y  N
Y N
Y  N
Y N
Y  N
