2 Introduction
The ZoneSense PLUS 4, 8 zone FACP complies with the highest level of approval for any applicable
code and can be connected to an appropriate Fire Service monitoring facility.
As a Minimum, the convenonal panel meets the following Standards;
Brish Standard BS 5839
European Standard EN54 Parts 2 & 4
The basic ZoneSense PLUS is available in a ABS (BX1) and Metal (BX10) cabinets and consists of a;
1. Main PCB, with all controls and indicators mounted directly onto it; and
2. A switch-mode power supply;
3. 2 X 12 Volt baeries connected in series.
4. 2 X ABS and / or 003 keys
Note: Only devices compable with ZoneSense PLUS should be used in an installaon. These are
listed in this document.
2.1 Features
➢ The front panel 8 x 2 line LCD, navigaon keys     and the Menu/Enter keys allow
the ZoneSense PLUS to be programmed on site. The same LCD and keys are also used for
panel operaon and interrogaon.
➢ Four monitored “Alarms” outputs.
➢ Two oponal auxiliary input connecons.
➢ Two current limited outputs (Fire [alarm] and Fault).
➢ Two relay outputs (ancillary and fault).
➢ Oponal external buzzer or reset output.
➢ System expansion capabilies / opons:
➢ Keyswitch/password entry to a wide range of engineering funcons which include;
1. Selectable zone delay;
2. Zone test;
3. Coincidence ( double-knock );
4. Non-latching zones;
5. Comprehensive fault diagnoscs;
➢ A wide range of secure user funcons. This includes the ability to disable/enable a large
number of system funcons.
➢ An “Alarm Time” feature is standard on all panels.
➢ Flush or surface mountable enclosure. A surround is required for the metal cabinet
➢ Controls have tacle and audible feedback of operaon.
➢ All terminals cater for 2.5mm cables.
