Ampac ZoneSense Plus - Page 8

MAN 2326-13
8
The BX1 front door is locked by way of two clips on the right hand side of the cabinet. A special
locang key which has two raised pins that are inserted into the side of the cabinet unlocks the door.
The BX1 can also be supplied with a 003 Key Lock if required. The BX10 box is locked with a 003 Key.
AMPAC
DOOR RELEASE PINS
DOOR RELEASE PINS
Figure 3: Plasc Key
147.00 mm147.00 mm
163.20 mm
Figure 4: ABS cabinet (BX1) Mounng Points
