ACR-5100 Acendo Core Administrators Guide

Control NetLinx:

•Master Code: URL, Auto, Listen

•ICSP Security: Yes

RS-232:

• Supported through USB using USB-DB9 adapter cable

Operation Button:

•Quick press: Sleep

• Press-and-hold: System Settings

Port Usage • 8888 TCP Group Manager

• 1319 TCP Remote Logging

•23 TCP Telnet logging

• 80 TCP Default port for AmxShare

•1319 UDP NetLinx

•587 Email Port

Processor: • a quad core Intel Celeron SoC

• x64 architecture and instruction set of 1.6 GHz which contains a burst option to 2.24 GHz

Operating System: • Windows 10 IoT Enterprise

Memory: • 4 GB RAM

• 120GB solid state drive (SSD) as the primary internal storage media

Supported Calendar

Systems:

• Microsoft Exchange 2013 SP1 or higher

• Microsoft Exchange 2016

• Exchange Online (Office 365)

Bluetooth: • 802.11a/b/g/n/ac standard protocol and frequency bands

•Bluetooth 4.0

• Meets Bluetooth SIG standards

• Bluetooth range (Min): 10 meters

HDMI Out: Two HDMI 2.0 Type A connectors for video output:

• Supports CEC protocol for display control

• HDCP specification 1.4

Continued 

Analog Audio: One 3.5mm mini-phono connector for stereo output:

• Supports two channels (left/right)

• Output Connection: 3.5 mm stereo audio jack

• Output Level (Max): 0 dBV (1 Vrms)

• Output Impedance: 100 Ohms

•Frequency Response: 20-20 kHz

•Dynamic Range: 90 dB

One 3.5mm mini-phono connector for single sided balanced audio input:

• Supports two channels (left/Right)

• Input Level (Max): 0 dBV (1 Vrms)

• Sampling frequencies: 32 kHz, 44.1 kHz, 48 kHz at both 16 bits and 24 bits

• Input impedance: 10k Ohms

Ethernet: Two 10/100/1000 Base T LAN ports for network connection via Cat5 cable.

• Connection: (2) RJ-45, Auto MDI/MDI-X

• Link/Act Indicator: (1) LED (green),

a. on when link is up

b. blink off for packet activity

c. off when link is down

• Speed Indicator: (1) LED

d. solid green when the speed on the link is 1000 Mbps

e. solid amber at 100 Mbps

f. off when the speed is 10 Mbps

• Support half and full-duplex

• Support IEEE 802.1X port-based Network Access Control (PNAC)

• Support WoL (Wake-on-LAN) feature (system awakens by a network message)
