Physical Installation

ACR-5100 Acendo Core Administrators Guide

Connections

FIG. 16 displays the ports provided on Acendo Core.

FIG. 15 ATTACH STAND-OFF SCREWS, INSERT THROUGH BACKPLATE

FIG. 16 ACENDO CORE CONNECTIONS

Insert Stand-off

Screws into Core

Align with slotted holes

and push the unit through

and slide down/back.

Dual Network

+12VDC Input

USB 3.0 Peripherals

Dual HDMI Output

(to 1-2 video monitors)

Microphone Input

(camera/microphone/speakers

Connections

Stereo Audio

Line Out

keyboard/mouse)

Power Button

Front

Rear

USB (Mouse, Keyboard, Memory Stick

with Status LED

and Thumb Drives
