Encoder Configuration Options
35
N1000 Series User Manual
IR Page
Click the IR link at the top of any of the main web pages to access the page shown in Figure 31. This page allows you to upload and
execute IR Pronto codes so that other vendor’s devices can be controlled through the Encoder’s IR connector. Commands can be
saved for future use and executed later. The IR Code menu lists all saved IR commands. See Ta b le 8
for option descriptions.
FIG. 31
IR Page
TABLE 8 IR Page Options
Option Description
IR Code Create/select IR codes. Different vendors have different IR Pronto codes and can usually be found through a web
search. Copy/paste new IR commands directly into the input space.
Save Save the current code.
Delete Delete the current code.
Execute Activate the selected code through the Encoder’s IR connector.
