Decoder Configuration Options
48
N1000 Series User Manual
Status Section
The Status section of the Settings page is shown in Figure 45. Options are described in Table 17.
FIG. 45
Status Section
TABLE 17 Settings Page: Status Section
Option Description Notes
HDMI Status Indicates if video is connected to the Decoder.
Input Resolution Indicates the video resolution of the incoming video
source.
Port 50001 Source IP Shows the IP address of the currently connected device
or displays Disconnected if no connection exists.
Port 50001 can only accept a single external
connection at a time. If a device is currently showing
the port occupied (by a control system or other
device), then other connections will be rejected.
However, connection attempts from the same IP will
override the current connection.
Port 50002 Source IP Shows the IP address of the currently connected device
or displays Disconnected if no connection exists.
Port 50002 can only accept a single external
connection at a time. If a device is currently showing
the port occupied (by a control system or other
device), then other connections will be rejected.
However, connection attempts from the same IP will
override the current connection.
Serial Source IP Shows the IP address of the currently connected device
or displays Disconnected if no connection exists.
Only a single external connection can be accepted on
the port. If a device is currently showing the port
occupied (by a control system or other device), then
other connections will be rejected. However,
connection attempts from the same IP will override
the current connection.
Flush buttons These buttons reset the port.
KVM IP Shows the IP address of the KVM Encoder currently
connected to this Decoder.
This setting only applies to the N1233.
