Decoder Configuration Options
43
N1000 Series User Manual
Decoder Setup Section
The Decoder Setup section of the Settings page is shown in Figure 41. Options are described in Table 13.
FIG. 41
Decoder Setup Section
TABLE 13 Settings Page: Decoder Setup Section
Option Description Notes
Device Name Enter a user-friendly name for the unit. More descriptive names in this field help you organize
and manage the SVSI system efficiently. Names
based on the unit’s location and function are very
useful. Some good examples are Lobby-Left-VGA (for
left side of lobby, VGA input) or CR201-HDMI (for
Conference Room 201, HDMI input). Keep in mind the
matrices are organized alphanumerically.
Stream View/edit the current transmit stream number. To better understand this setting, think of Decoders
dialing up channels on a cable box, rather than a
traditional AV matrix. Each decoder can dial in a
different active channel.
Audio Stream View/edit the current audio receive stream number.
Audio Follows Video Enable to force the Audio Stream to the same as the
video stream.
Scaler Enable to scale outgoing content to a fixed resolution or
to use the Crop/Pan/Zoom functions.
Output Mode Select the output resolution of the video to be
transmitted to the video output device (e.g., LCD). The
Scaler check box must be enabled for this to be
applicable.
Live/Local Select live video or locally stored images for
transmission to the video output device (e.g., LCD).
When video is not available, it automatically goes into
local mode.
When video is not available, the most recently played
local playlist is displayed.
Mute Enable to mute output audio.
