SECTION 6 PERFORMANCE TESTS
6-26
• MS2665C
2.000 01 GHz 2 GHz 1 –95 dBc/Hz
6.000 01 GHz 6 GHz 1 –95 dBc/Hz
10.000 01 GHz 10 GHz 2 –89 dBc/Hz
20.000 01 GHz 20 GHz 3 –85.5 dBc/Hz
Center
frequency
Signal
generator
Harmonic order
at mixer
Results Spec.
• MS2667C
2.000 01 GHz 2 GHz 1 –95 dBc/Hz
6.000 01 GHz 6 GHz 1 –95 dBc/Hz
10.000 01 GHz 10 GHz 2 –89 dBc/Hz
20.000 01 GHz 20 GHz 3 –85.5 dBc/Hz
26.500 01 GHz 26.5 GHz 4 –83 dBc/Hz
Center
frequency
Signal
generator
Harmonic order
at mixer
Results Spec.
• MS2668C
2.000 01 GHz 2 GHz 1 –95 dBc/Hz
6.000 01 GHz 6 GHz 1 –95 dBc/Hz
10.000 01 GHz 10 GHz 2 –89 dBc/Hz
20.000 01 GHz 20 GHz 4 –85.5 dBc/Hz
26.000 01 GHz 26 GHz 4 –83 dBc/Hz
39.000 01 GHz 39 GHz 6 –80 dBc/Hz
Center
frequency
Signal
generator
Harmonic order
at mixer
Results Spec.
