SECTION 6 PERFORMANCE TESTS
6-54
(4) Procedure
Step Procedure
1 Press the spectrum analyzer [Preset] key.
2 Operate All Cal.
3 Set the spectrum analyzer as shown below:
Center Freq............................................100 MHz
Span........................................................ 200 kHz
4 Set the signal generator MG3633A as shown below:
OUTPUT FREQ....................................100 MHz
OUTPUT LEVEL ................................. –10 dBm
5 Set the amount of attenuation of the attenuator MN510C to 0 dB.
6 Connect the output of the attenuator MN510C to the power meter via coaxial cable.
7 Adjust the signal-generator output level so that the indicated value of the power meter is -
10.0 dBm.
8 Connect the coaxial cable of the attenuator output to the spectrum analyzer RF Input.
9 Press the [→ CF] key.
10 Set the reference level to –10 dBm and attenuation to 50 dB.
11 Read the marker level.
12 Set Reference Level, ATT of this device and the external ATT as shown in the table on the
next page, and read the level of each marker.
13 Find the error by the formula below:
Error = marker readout-Reference Level-correction factor of attenuator
14 Find the deviation by the formula below:
Deviation = Error-error when ATT at 10 dB
Confirm that the deviation is within ±0.3 dB.
To Next Page
