APPENDIX C
C-22
Reference level accuracy
Reference Level Marker Correction factor
Error*1 Spec.
setting readout of ATT
0dBm ±0.4dB
–10dBm ±0.4dB
–20dBm ±0.4dB
–30dBm ±0.4dB
–40dBm ±0.4dB
–50dBm ±0.75dB
–60dBm ±0.75dB
–70dBm ±1.5dB
–80dBm ±1.5dB
*1: Calculate the “Error” from the following equation
Error=Marker readout–Reference Level set value–corection factor of ATT
DATE
SERIAL NO.
Tested by
MS2667C Performance Test Record
(8/12)
