APPENDIX C
C-23
MS2667C setting Average noise level
START FREQ STOP FREQ Band
Marker readout
Specification
(dBm)
1MHz 10MHz 0 –115dBm
10MHz 100MHz 0 –115dBm
100MHz 1GHz 0 –115dBm
1GHz 2GHz 0 –113.5 to –112dBm
2GHz 3.1GHz 0 –112 to –110.35dBm
3.1GHz 4GHz 1––110dBm
4GHz 5GHz 1––110dBm
5GHz 6GHz 1––110dBm
6GHz 6.5GHz 1––110dBm
6.4GHz 7GHz 1+ –110dBm
7GHz 8.1GHz 1+ –110dBm
8GHz 9GHz 2+ –102dBm
9MHz 10GHz 2+ –102dBm
10GHz 11GHz 2+ –102dBm
11GHz 12GHz 2+ –102dBm
12GHz 13GHz 2+ –102dBm
13GHz 14GHz 2+ –102dBm
14MHz 15.3GHz 2+ –102dBm
15.2GHz 16GHz 3+ –98dBm
16GHz 17GHz 3+ –98dBm
17GHz 18GHz 3+ –98dBm
18GHz 19GHz 3+ –98dBm
19GHz 20GHz 3+ –98dBm
20GHz 21GHz 3+ –98dBm
21MHz 22.4GHz 3+ –98dBm
22.3GHz 23GHz 4+ –91dBm
23GHz 24GHz 4+ –91dBm
24GHz 25GHz 4+ –91dBm
25GHz 26GHz 4+ –91dBm
26GHz 27GHz 4+ –91dBm
27GHz 28GHz 4+ –91dBm
28GHz 29GHz 4+ –91dBm
29GHz 30GHz 4+ –91dBm
Average noise level
DATE
SERIAL NO.
Tested by
MS2667C Performance Test Record
(9/12)
