SECTION 1 GENERAL
1-19
(Continued)
Model MS2668C
Input connector K-J, 50Ω
Auxiliary signal input and output
IF OUTPUT:BNC connector, 10.69MHz
VIDEO OUTPUT (Y): BNC connector,100 MHz input, 75Ω terminated
0 to 0.5V (0.1V nominal (from lower edge to upper edge at 10dB/div)
0 to 0.4V (0.1V nominal (from lower edge to upper edge at 10%/div)
COMPOSITE OUTPUT: For NTSC, 1Vp-p (75Ω terminated), BNC connector
EXT REF INPUT:10MHz ±10Hz, ≥0dBm (50Ω terminated), BNC connector
Power (operating range) AC 85 to 132 V/AC 170 to 250 V (automatic voltage switching),
47.5 to 63Hz, 380 to 420Hz (AC 85 to 132 V only), ≤400VA
Conducted disturbance Meets EN 61326-1: 2006 (Class A)
Radiation disturbance Meets EN 61326-1: 2006 (Class A)
Harmonic Current Emission Meets EN 61000-3-2: 2006 (Class A)
Electrostatic Discharge Meets EN 61326-1: 2006 (Table 2)
Electromagnetic Field Immunity Meets EN 61326-1: 2006 (Table 2)
Fast Transient / Burst Meets EN 61326-1: 2006 (Table 2)
Surge Meets EN 61326-1: 2006 (Table 2)
Conducted RF Meets EN 61326-1: 2006 (Table 2)
Power Frequency Magnetic Field Meets EN 61326-1: 2006 (Table 2)
Voltage Dips / Short Interruptions Meets EN 61326-1: 2006 (Table 2)
Vibration Meets MIL-STD-810D
Dimensions and mass 177 (H) × 320 (W) × 381 (D), ≤15kg (without option)
Ambient temperature 0 to 50˚C (operate), –40 to 75˚C (storage)
Others
