E-ITN 30
Installation and service manual M2019/01a [EN]
4.4.1. Submenu structure in mode of waiting for start date
For submenu activation and navigation between items see chapter 4.2. Submenu navigation. Allocator self
test activation is described in chapter 4.3.1.2. Allocator self test. Radiator type selection E-ITN 30.3 is
described in chapter 4.3.1.3. Setting of radiator type (E-ITN 30.3 only).
Table 4: Submenu structure in mode of waiting for start date, type E- ITN 30.2 and 30.4
Allocator self-test ti
Table 5: Submenu structure in mode of waiting for start date, type E- ITN 30.3
Radiator type (e.g. 2) tot 2
Heat output of the radiator (e.g. 5000 W) 5000
Coefficient K
CHF
(e.g. 1.050) 1.050
Allocator self-test ti
4.5. WORKING MODE
In working mode, allocator performs temperature measurement, calculates the increase of valuecal (if
measurement conditions are met), transmits measured data, updates real-time and makes some other
actions in regular intervals.
4.5.1. Menu structure in working mode
If nothing is displayed press the button briefly.
Table 6: Submenu structure in working mode, type E-ITN 30.2 a 30.4
Value for current billing period 245
Value for last billing period 458 SM
Alphanumerical code for last billing period A0iht
Serial number – first part -3400
Serial number – second part 0060-
* Radiator temperature 53.3°C
* Surroundings temperature 26.7°C SM
* Date of billing period beginning - E-ITN 30.2
- E-ITN 30.4
U 1.12.
dF 1
* Current date 10.12.
* Current time 12-45
Note: menu items marked as * are optional, see chapter 5.2. Allocator parameters setting.
Table 7: Submenu structure in working mode, type E-ITN 30.3
LCD test
Current date 10.12.
Start of the billing period u 1.2.
Value for last billing period 458 SM
Alphanumerical code A0iht
Average surroundings temperature for last billing
period
23.7°C SM
Value for current billing period 245
11 / 46
