7.18. PATTER NO. 11 – ALUMINIUM RADIATOR WITH VERTICAL RIBS
Verified on: FONAL TYP A 650-175, manufacturer: Kovohutě Mníšek
Basic dimensions of the FONAL A 650-175 and data for correct allocator installation (mm):
Height Mounting distance MM
650 500 0009
Heat output Q
N
[W] of the radiator can be found in manufacturer catalogue: Fonal Kovohutě Mníšek, Mníšek
pod Brdy
Table 21: Types of heating elements belonging to the model group 11
