E-ITN 30
Installation and service manual M2019/01a [EN]
4.5.2. Structure of submenu with month values ( E-ITN 30.2, 30.4 only)
Enter submenu from the main menu. When the display is on and 1
st
menu item is displayed (value for the
current billing period, e.g. 389), press and hold the button, till notice --A--, is displayed. After button release,
1
st
submenu item du is displayed (month values).
Table 8: Submenu structure in working mode, type E-ITN 30.2 and 30.4
Month values du
Allocator self-test ti
To switch between the submenu items, press the button shortly. If the button is not pressed in 20 seconds,
allocator switches back to the main menu and the 1
st
item will be displayed.
Measured month values can be displayed 11. moths back from the current date. When submenu item
„month value“ du is displayed press and hold the button till –A-- appear. After release, current month number
- 0 is displayed.
Table 9: Structure of submenu with month values, type E- ITN 30.2 a 30.4
Current month - 0
Value for the current billing period 389
Last month - 1
Value at the end of the last month 245
... ...
11
th
month back - 11
Value at the end of the 11
th
month back 1989
Total number of displayed items is 24.
To switch between submenu items, press the button shortly. To end this submenu, do not press the button for
20 seconds, allocator will switch back to the main menu and the 1
st
item (value for the current billing period)
will be displayed. Also the long button press can be used to exit. Press and hold the button till --A-- appears.
After release, menu item „value for the current billing period“, e.g. 389 is displayed.
Procedure how to run allocator test is described in chapter 4.3.1.2. Allocator self test.
4.5.3. Structure of submenu with month values (E-ITN 30.3 only)
Measured month values can be displayed 11 months back from the current date. When display is on and
item “value for last billing period“ (e.g. 3258 SM) is displayed, press and hold the button till notice --A--
appears. After release actual date is displayed as e.g. 10.07 (10 - month, 07 - the last two digits of the year).
Table 10: Structure of submenu with month values, type E-ITN 30.3
m0 – current moth, r0 - last two digits of the year „m0. r0“
x0 – value for current billing period „x0“
m1 – last month, r1 - last two digits of the year „m1. r1“
x1 – value at the end of the last month „x1“
... ...
m11 - 11. month back, r11 - last two digits of the year „m11. r11“
x11 – value at the end of the 11
th
month back „x11“
Total number of displayed items is 24.
Except current moth, values correspond with measured values at the end of the month from the beginning of
the billing period.
To switch between submenu items, press the button shortly. To end this submenu, do not press the button
for 20 seconds, allocator will switch back to the main menu and the 1
st
item (LCD test) will be displayed. Also
13 / 46
