7.12. MODEL NO. 5 – STEEL RADIATORS WITH DISTANCE PAD
Verified on: Svratouch 500/160, manufacturer: Dílo - Svratouch
Basic dimensions of the SVRATOUCH 500/160 for 10 segments, data for correct allocator installation (mm):
Height- H Mounting distance - h Length- L Segment length - l Depth - B MM
600 500 500 50 160 0002
Heat output Q
N
[W] of the 500/160 radiator can be found in manufacturer catalogue: Dílo, výrobní a obchodní
družstvo, 539 42 Svratouch
Table 16: Types of heating elements belonging to the model group 5
Type of the radiator Manufacturer of the radiator MM
1 500/185 Dílo - Svratouch 0002
2
3
4
5
6
7
8
9
10
35 / 46
