7.3. LIST OF INSTALLATION MATERIAL
Mounting material is used to install allocator to the radiator. Manufacturer does not guarantee the accuracy of
coefficient Kc when used a different installation material.
Type Mounting accessories content
0001 bolt M4x25 + serrated lock washer + clamp III
0002 bolt M4x50 + serrated lock washer + clamp IV + spacer 45
0003 bolt M4x35 + serrated lock washer + clamp III
0004 bolt M4x50 + serrated lock washer + clamp III
0005 bolt M4x115 + serrated lock washer + clamp III
0006 bolt M4x25 + serrated lock washer + clamp
0007 bolt M4x80 + serrated lock washer + clamp III
0008 2 pcs nut M3 special + 2 pcs serrated lock washer + clamp FONAL (8 mm)
0009 2 pcs screw DIN 7982 ST 2.2x16 shape Z
0010 2 pcs nut M3 special + 2 pcs serrated lock washer + clamp FONAL (10 mm)
0011 2 pcs nut M3 special + 2 pcs serrated lock washer + clamp FONAL (12 mm)
0012 2 pcs bolt M3x6 type G AlMg3 + 2 pcs serrated lock washer + 2 pcs nut M3 special
0051 2 pcs bolt M3x6 type G + 2 pcs serrated lock washer + 2 pcs nut M3 special
0052 2 pcs bolt M3x10 type G + 2 pcs serrated lock washer + 2 pcs nut M3 special
0053 2 pcs bolt M3x12 type G + 2 pcs serrated lock washer + 2 pcs nut M3 special
0054 2 pcs bolt M3x10 type G + 2 pcs serrated lock washer + 2 pcs nut M3 special + spacer
0055 bolt M3x6 type G + 2 pcs bolt M4x8 + nut M3 + spacer – tubular heating radiator
0056 bolt M4x25 + serrated lock washer + clamp III
0057 2 pcs bolt M3x8 type G DIN 32 501 ST 36-2 + 2 pcs serrated lock washer + 2pcs nut M3 spec.
