7.21. MODEL NO. 14 – RADIATORS KORATHERM HORIZONTAL K22HM
Verified on: Koratherm horizontal K22HM, manufacturer: KORADO a.s., Bří Hubálků 869, 560 02 Česká
Třebová
Basic dimensions of the Koratherm horizontal K22HM radiator and data for correct allocator installation
(mm):
Height - H Mounting distance - h Length MM
218 50 500 52
Heat output Q
N
[W] of the radiator can be found in manufacturer catalogue: KORADO a.s., Bří Hubálků 869,
560 02 Česká Třebová
Tabulka 24: Types of heating elements belonging to the model group 14
Type of the radiator Manufacturer of the radiator MM
1 KORATHERM horizontal K22HM KORADO a.s. 52
