ONE by APOGEE – User’s Guide
Apogee Maestro 2
Input Tab Window
1. Analog Level - Use this menu to select internal
microphone, external microphone, external 48V microphone,
or instrument.
3. Input Level - The gain of each input is controlled with this
software knob. The gain level is indicated in the value box
below the knob.
4. Analog Input Meter - This meter displays the level of the
analog input after A/D conversion.
Output Tab Window
1. Analog Output Meter - This meter displays the level of
the analog output before D/A conversion, in the range -48 to
0 dBFS.
2. Speaker Out Selection - This menu selects the software
output that is sent to ONE’s output.
3. Speaker Out Level - This knob controls the output level.
Mute - Engage this to mute ONE’s output.
