AT682/683 Users Manual
38
Parameters
{<integer>,MIN,MAX}
where
<interger> Range no from 1 to 6.
MIN =1
MAX =6
For example
Tx> func:rang 5 //set range to 5
Tx> func:rang min //set range to 1
Tx> func:rang max //set range to 7
Query Syntax
FUNCtion:RANGe?
Query Response
<integer> Range no from 1 to 6.
For example
Tx> func:rang?
Rx> 6
Constraints
none
:RANGe:AUTO
The :RANGe:AUTO command sets the auto range to ON or OFF.
Command Syntax
FUNCtion:RANGe:AUTO {ON,OFF,1,0}
Parameters
{ON,OFF,1,0}
where,
1 =ON ASCII(decimal 49)
0 =OFF ASCII(decimal 48)
For example
Tx> func:rang:auto off //The auto range will set to manual.
Query Syntax
FUNCtion:RANGe:AUTO?
Query Response
{on,off}
For example
Tx> func:rang:auto?
Rx> off
Constraints
none
7.7 VOLTage Subsystem
The VOLTage subsystem sets test voltage.
Figure7-3
VOLTage
Command Tree
Command Syntax
VOLTage <float>
Parameters
<float> 1.0~650
For example
Tx> VOLT 10.2
Tx> VOLT 500
Query Syntax
VOLTage?
Query Response
<float> 1.0~650.0
VOLTage
<float>
