AT682/683 Users Manual
28
5 Handler Interface
This chapter describes how to use the handler interface.
Pin Assignment
Circuit Diagram
Timing Chart
By using the handler interface, you can output the measurement completion signal (EOC),
the screening result of the comparator function (GD/NG), and so on to external devices
from the AT682/683. You can also input the external trigger signal and the comparator
select signal to the AT682/683. With this interface and the comparator function, you can
build an automatic screening system composed of the AT682/683 and the handler.
5.1 Pin Assignment
Figure 5-1 Pin Assignment of Handler Interface Connector
Table 5-1 Description of Handler Interface Input Signals
9
COMP.0
Comparator Record Selector.
(1 thru 30)
See Table 5-1.
10
COMP.1
11
COMP.2
12
COMP.3
