Page #25 background imageLoading...
Page #25 background image
3. Startup
25
3.5.4 Display IR and Leakage at one time.
AT682/683 can display IR at 1
st
line of the VFD and Leakage current at 2
nd
line.
Under TEST STATEPress View key to choose follow items at 2
nd
line:
Ix or Rx Leakage Current or IR (According to the different parameter)
Peak
GD/NG Sorting Result
3.5.4 Display Peak
Press View key to display peak at VFD 2
nd
line.
TIP:
IRs peak is Minimum, the MIN annunciator displayed.
Leakage Currents peak is Maximum, the MAX annunciator displayed.
3.5.5 Display Sorting Result
Press View key to display sorting result (GD/NG) at VFD 2
nd
line.
3.5.6 Turning ON/OFF the Beep Feature.
The AT682/683 has a beep feature which generates beeps when the following two
conditions have been occurred:
The DUT is out of range limit and the situation has been sorted as NG by the
comparator.
The DUT is in the range limit and the situation has been sorted as GD by the
comparator.
Regardless of whether the beep feature is on or off, beeps are generated whenever:
AT682/683 starts up
Key pressed.
An error message or warning message has appeared.
To set up the beep feature:
Press Beep to turn on or turn off the beep feature. A beep annunciator shows you the beep
on/off state.
Refer chapter 4, Comparator, to set beep feature.
