1. Unpacking and Preparation
11
1.2 Power Supply
Confirm that the power supplied to the AT682/683 meets the following
requirements:
Voltage198-252VAC
Frequency47.5-52.5Hz
Power-consumption: 30VA max
1.3 Setting up Fuse
~Line: 47.5Hz-52.5Hz
198Vac - 242Vac
50VA MAX
Fuse: 250V 1A
Slow Blow
~Line: 47.5Hz-52.5Hz
198VAC 242VAC
30VA MAX
Fuse: 250V 1A
Slow Blow
Figure 1-1 Fuse Holder
Please use the following fuse type.
UL/CSA type, Slow-Blow, 5×20-mm miniature fuse, 1A, 250 V
When you need a fuse, contact your nearest Applent Instruments sales or service office.
To verify and replace the fuse, remove the power cable and pull out the fuse holder.
NOTE
Two fuses in Fuse Holder.
1.4 How to Remove the Handle
A handle kit is attached to the AT682/683.
