Generator Settings screen 3/3
* P147
Options:
Gener. sound .................. enable (ON) or disable (OFF) the alarm of ongoing signal generation
BACK CONTROL:
Enable .................... enable (ON) or disable (OFF) loopback function
Repeat .................... number of occurrence of loopback function - Once, Twice,
Infinite (occurs repeatedly while the Generation lasts)
SOFT GENERATE:
Enable .................... enable (ON) or disable (OFF) Soft Generate function
Delay ...................... duration of Soft Generate function; stated in milliseconds
Network Freq. Sync. ....... enable (ON) or disable (OFF) synchronization of network frequency
Norm. to 1st. Harm .......... normalizing (ON) to first harmonic and the RMS value will arise with
crescent number of harmonics. OFF means normalizing to all harmonics
and the overall RMS value remains as set in generator.
DOSAGE:
Enable .................... enable (ON) or disable (OFF) Dosage function
Soft start ................ enable (ON) or disable (OFF) of Soft Generate function for Dosage
starting
Soft stop ................. enable (ON) or disable (OFF) of Soft stop for Dosage ceasing (opposite
to soft start). “Soft stop enabled” negatively impacts the Dosage function
accuracy.
Stop Voltage .......... enable (ON) or disable (OFF) ceasing voltage generation after set dose
was generated. OFF means no change in voltage generation will be
carried out. Value of set dose is modifiable, see chapter 5.7.2 Test
Settings, Dial tests.
Stop Current .......... enable (ON) or disable (OFF) ceasing current generation after set dose
was generated. OFF means no change in current generation will be
carried out. Value of set dose is modifiable, see chapter 5.7.2 Test
Settings, Dial tests. This might be useful for correct dial (register) final
reading after Register (Dial) test.
