Portable Test Equipment
User’s Guide
PTE-UGFW56a-EN www.appliedp.com
34
List of displayed quantities:
U, U
PN
......... Phase to neutral voltage
U
PP
.............. Phase to phase voltage
I ................... Current
P.................. Active Power
Q ................. Reactive Power
S.................. Apparent Power
cos φ, sin φ ..... Power Factor (with LAG or
LEAD indication in last column) *
................ Phase of U
PN
Voltage
PP
............. Phase of U
PP
Voltage
Z ................ Load Impedance
Z
................ Phase shift of Load Impedance
........... Phase of Current
........... Distortion Factor of Voltage
........... Distortion Factor of Current
............ Active Power of Harmonics (2
nd
-N
th
) *
I
P
............ Active Current
I
Q
............ Reactive Current
P
1ST
........ Active power of the first harmonic
f ............ Frequency
L1xx ..... Voltage Phase Seq. (L123 or L132)
L
I
1xx ..... Current Phase Seq. (L
I
123 or L
I
132) *
* Display of some quantities can be enabled / disabled in Measurement Settings under F5.
Control keys:
F1 .......... Energy Values
F2 ........... Meter Error Test
F3 ………. Transformer Test
F4 ........... Data Readout
F5 .......... Menu
◄ ► ....... Scroll Load Values screens: LVa <-> LVa1 <-> LVa2 <-> LVa3 <-> LVa respectively LVb <->
LVb1 <-> LVb2 <-> LVb3 <-> LVb
To scroll Load Values screens (LVa <-> LVb <-> LVc <-> LVd <-> LVa) use arrows ▼▲ or PgUP and PgDn
keys.
LVc and LVd screens show primary values which depend on CT / VT ratio defined for actual meter.
